| 序號 | 項目（Project） | 單位（Unit） | ZWY-60 | ZWY-80/24.2T | ZWY-100 | ZWY-120 |
| 1 | 裝載能力 Loading capacity |
m³/h | ≥60 | ≥80 | ≥100 | ≥120 |
| 2 | 整機重量 The weight |
kg | 4800 | 4800 | 5200 | 6800 |
| 3 | 轉(zhuǎn)彎半徑下限 Turning radius |
mm | ≤4000 | ≤4000 | ≤4000 | ≤4000 |
| 4 | 挖掘?qū)挾?br />Mining width | mm | ≥2500 | ≥2800 | ≥3200 | ≥3500 |
| 5 | 挖掘高度 Mining height |
mm | ≥2800 | ≥2800 | ≥3200 | ≥3500 |
| 6 | 挖掘深度 Digging depth |
mm | ≥700 | ≥700 | ≥700 | ≥700 |
| 7 | 挖取距離 Harvest distance |
mm | ≥1300 | ≥1300 | ≥1600 | ≥2000 |
| 8 | 卸載高度 Discharge height |
mm | ≥1600 | ≥1600 | ≥1800(可加高) | ≥2000(可加高) |
| 9 | 爬坡能力 Climbing ability |
(°) | -18~+18 | -18~+18 | -18~+18 | -18~+18 |
| 10 | 行走速度 Walking speed |
Km/h | 0.70±0.03 | 0.70±0.03 | 0.70±0.03 | 0.70±0.03 |
| 11 | 離地間隙 Clearance from the ground |
mm | ≥200 | ≥200 | ≥250 | ≥320 |
| 12 | 額定工作壓力 Rated working pressure |
mpa | 16 | 16 | 18 | 18 |
| 13 | 安全閥開啟壓力 Relief valve opening pressure |
mpa | 19.2 | 19.2 | 21 | 21 |
| 14 | 電機總功率 Total motor power |
kw | 15 | 22 | 37 | 45 |
| 15 | 外形尺寸(長*寬*高)運輸狀態(tài) Overall dimensions |
mm | 5200×1550×1550 | 5800×1700×1800 | 6200×1800×1800 | 9800×1850×2660 |
